929836-05-19

Product Name 929836-05-19

Manufacturer 3M

Describe CONN HEADER VERT 38POS 2.54MM

Classification: Rectangular Connectors - Headers, Male Pins

Datesheet 3mtmpinstriphdr-100-100x-100-929-series-ts0769.pdf
3m-interconnect-products-shortform-catalog.pdf

Stock 9999

Customer Reference

9999 In Stock

More quantities are on the way.

Product Attributes

Type PARAMETERS

Pitch - Mating

0.100" (2.54mm)

Contact Shape

Square

Style

Board to Board

Contact Finish Thickness - Post

Operating Temperature

-40°C ~ 105°C

Contact Type

Male Pin

Number of Rows

Insulation Height

0.100" (2.54mm)

Contact Finish Thickness - Mating

100.0µin (2.54µm)

Mated Stacking Heights

Series

929

Package

Bulk

Connector Type

Header

Number of Positions Loaded

All

Contact Finish - Mating

Tin-Lead

Ingress Protection

Insulation Color

Black

Termination

Solder

Overall Contact Length

0.945" (24.00mm)

Insulation Material

Polybutylene Terephthalate (PBT), Polyester, Glass Filled

Applications

Mfr

Features

Row Spacing - Mating

0.100" (2.54mm)

Fastening Type

Push-Pull

Current Rating (Amps)

2.5A

Base Product Number

929836

Product Status

Active

Number of Positions

Contact Length - Mating

0.235" (5.97mm)

Contact Finish - Post

Contact Material

Copper Alloy

Shrouding

Unshrouded

Mounting Type

Through Hole

Contact Length - Post

0.610" (15.49mm)

Material Flammability Rating

UL94 V-0

Voltage Rating
