N3428-5203RB

Product Name N3428-5203RB

Manufacturer 3M

Describe CONN HEADER R/A 20POS 2.54MM

Classification: Rectangular Connectors - Headers, Male Pins

Datesheet 3m-interconnect-products-shortform-catalog.pdf
3m-four-wall-header-3000-series-100-x-100-ts-0772.pdf

Stock 9999

Customer Reference

9999 In Stock

More quantities are on the way.

Product Attributes

Type PARAMETERS

Contact Shape

Square

Number of Positions

Style

Board to Board or Cable

Insulation Material

Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled

Features

Keying Slot, Mounting Flange

Contact Finish Thickness - Mating

30.0µin (0.76µm)

Contact Finish - Post

Tin

Insulation Color

Black

Applications

Mfr

Fastening Type

Latch Lock/Eject Hooks, Short

Contact Length - Post

0.155" (3.94mm)

Series

3000

Number of Positions Loaded

All

Mated Stacking Heights

Contact Finish Thickness - Post

200.0µin (5.08µm)

Termination

Solder

Insulation Height

0.340" (8.64mm)

Number of Rows

Contact Length - Mating

0.240" (6.10mm)

Overall Contact Length

Ingress Protection

Voltage Rating

Connector Type

Header

Row Spacing - Mating

0.100" (2.54mm)

Shrouding

Shrouded - 4 Wall

Mounting Type

Through Hole, Right Angle

Base Product Number

N3428

Product Status

Active

Contact Type

Male Pin

Contact Material

Copper Alloy

Material Flammability Rating

UL94 V-0

Current Rating (Amps)

1.75A

Package

Bulk

Pitch - Mating

0.100" (2.54mm)

Contact Finish - Mating

Gold

Operating Temperature

-55°C ~ 105°C
