2068322001

2068322001
Molex
CONN HEADER VERT 20POS 3MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Mounting Type
Through Hole
Series
Micro-Fit+ 206832
Row Spacing - Mating
0.118" (3.00mm)
Contact Finish - Mating
Tin
Contact Length - Post
0.125" (3.18mm)
Base Product Number
206832
Connector Type
Header
Style
Board to Cable/Wire
Termination
Solder
Contact Finish Thickness - Mating
-
Overall Contact Length
-
Insulation Height
0.390" (9.91mm)
Pitch - Mating
0.118" (3.00mm)
Number of Positions
20
Number of Rows
2
Fastening Type
Locking Ramp
Contact Length - Mating
-
Mfr
Molex
Package
Tray
Contact Type
Male Pin
Contact Shape
Square
Ingress Protection
-
Number of Positions Loaded
All
Shrouding
Shrouded - 4 Wall
Material Flammability Rating
UL94 V-0
Mated Stacking Heights
-
Applications
Automotive, General Purpose, Medical, Telecommunications
Features
Board Guide, Glow Wire Compliant
Operating Temperature
-40°C ~ 105°C
Insulation Color
Black
Product Status
Active
Contact Material
Copper Alloy
Current Rating (Amps)
12.5A per Contact
Voltage Rating
600VAC/DC
Contact Finish - Post
Tin
Insulation Material
Liquid Crystal Polymer (LCP), Glass Filled
Contact Finish Thickness - Post
-
