3-178136-5
3-178136-5
Favorite Products
Share:

3-178136-5

3-178136-5
TE Connectivity AMP Connectors
CONN HEADER VERT 3POS 5.08MM
Headers, Male Pins
Available
RoHS Compliant
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Material Flammability Rating
UL94 V-0
Row Spacing - Mating
-
Shrouding
Shrouded - 4 Wall
Product Status
Active
Style
Board to Board or Cable
Insulation Height
0.850" (21.59mm)
Voltage Rating
600V
Series
Dynamic D-3200
Number of Rows
1
Contact Finish - Post
Tin
Fastening Type
Detent Lock
Contact Length - Mating
-
Contact Material
Copper Alloy
Operating Temperature
-55°C ~ 105°C
Applications
General Purpose, Industrial
Base Product Number
178136
Connector Type
Header
Contact Type
Tab
Contact Finish - Mating
Tin
Ingress Protection
-
Mfr
TE Connectivity AMP Connectors
Package
Tube
Mounting Type
Through Hole
Contact Length - Post
0.150" (3.81mm)
Contact Shape
Rectangular
Mated Stacking Heights
31.00mm ~ 32.50mm
Pitch - Mating
0.200" (5.08mm)
Number of Positions Loaded
All
Contact Finish Thickness - Post
-
Number of Positions
3
Features
Board Lock
Current Rating (Amps)
-
Overall Contact Length
-
Insulation Material
Thermoplastic, Polyester, Glass Filled
Termination
Solder
Contact Finish Thickness - Mating
78.7µin (2.00µm)
Insulation Color
Black
