3428-L302
3428-L302
Favorite Products
Share:

3428-L302

3428-L302
3M
CONN HEADER R/A 20POS 2.54MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Number of Positions Loaded
All
Product Status
Obsolete
Contact Shape
Square
Package
Bulk
Features
Keying Slot, Mounting Flange
Ingress Protection
-
Current Rating (Amps)
1A
Applications
-
Series
3000
Contact Finish - Mating
Gold
Overall Contact Length
-
Insulation Color
Black
Contact Finish Thickness - Post
200.0µin (5.08µm)
Insulation Height
0.660" (16.76mm)
Shrouding
Shrouded - 4 Wall
Termination
Solder
Contact Length - Mating
0.240" (6.10mm)
Material Flammability Rating
UL94 V-0
Row Spacing - Mating
0.100" (2.54mm)
Style
Board to Board or Cable
Fastening Type
Latch Lock/Eject Hooks, Long
Mfr
3M
Number of Rows
2
Contact Length - Post
0.112" (2.84mm)
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Contact Material
Copper Alloy
Operating Temperature
-55°C ~ 105°C
Voltage Rating
-
Connector Type
Header, Stackable (2)
Mounting Type
Through Hole, Right Angle
Contact Finish - Post
Tin-Lead
Mated Stacking Heights
-
Contact Type
Male Pin
Pitch - Mating
0.100" (2.54mm)
Number of Positions
20, 20
Insulation Material
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Base Product Number
3428
