3431-5305

3431-5305
3M
CONN HEADER R/A 34POS 2.54MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Features
Keying Slot, Mounting Flange
Base Product Number
3431
Number of Positions Loaded
All
Mfr
3M
Number of Positions
34
Contact Finish - Mating
Gold
Voltage Rating
-
Product Status
Active
Pitch - Mating
0.100" (2.54mm)
Mounting Type
Through Hole, Right Angle
Contact Material
Copper Alloy
Contact Finish Thickness - Post
Flash
Contact Type
Male Pin
Shrouding
Shrouded - 4 Wall
Insulation Height
0.340" (8.64mm)
Insulation Material
Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Series
3000
Connector Type
Header
Style
Board to Board or Cable
Contact Finish - Post
Gold
Mated Stacking Heights
-
Row Spacing - Mating
0.100" (2.54mm)
Fastening Type
Latch Lock/Eject Hooks, Long
Material Flammability Rating
UL94 V-0
Current Rating (Amps)
1A
Termination
Wire Wrap
Overall Contact Length
-
Contact Length - Mating
0.240" (6.10mm)
Insulation Color
Black
Applications
-
Package
Bulk
Number of Rows
2
Contact Length - Post
0.610" (15.49mm)
Contact Shape
Square
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Ingress Protection
-
Operating Temperature
-55°C ~ 105°C
