3764-D303
3764-D303
Favorite Products
Share:

3764-D303

3764-D303
3M
CONN HEADER R/A 64POS 2.54MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Base Product Number
3764
Shrouding
Shrouded - 3 Wall
Current Rating (Amps)
1A
Contact Length - Mating
0.240" (6.10mm)
Features
Keying Slot, Mounting Flange
Pitch - Mating
0.100" (2.54mm)
Number of Rows
2
Insulation Material
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Contact Length - Post
0.155" (3.94mm)
Contact Finish Thickness - Mating
30.0µin (0.76µm)
Insulation Color
Black
Mated Stacking Heights
-
Number of Positions
64, 64
Row Spacing - Mating
0.100" (2.54mm)
Mfr
3M
Connector Type
Header, Stackable (2)
Insulation Height
0.660" (16.76mm)
Contact Shape
Square
Fastening Type
Latch Lock/Eject Hooks, Long
Ingress Protection
-
Voltage Rating
-
Mounting Type
Through Hole, Right Angle
Termination
Solder
Contact Finish - Mating
Gold
Contact Finish - Post
Tin-Lead
Material Flammability Rating
UL94 V-0
Style
Board to Board or Cable
Overall Contact Length
-
Series
3000
Package
Bulk
Contact Material
Copper Alloy
Operating Temperature
-55°C ~ 105°C
Contact Finish Thickness - Post
200.0µin (5.08µm)
Applications
-
Product Status
Obsolete
Contact Type
Male Pin
Number of Positions Loaded
All
Related Products
FSH-135-04-L-DH-SL

Samtec Inc.
TMMH-127-04-F-T

Samtec Inc.
MTSW-222-12-T-D-730-RA

Samtec Inc.
MTMM-116-08-S-S-380

Samtec Inc.
B05B-XASK-1N-A-LF-SN

JST Sales America Inc.
92632-110HLF

Amphenol ICC (FCI)
6-104909-6
