M22-2032046
M22-2032046
Favorite Products
Share:

M22-2032046

M22-2032046
Harwin Inc.
CONN HEADER R/A 20POS 2MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Contact Finish - Mating
Tin
Style
Board to Board
Current Rating (Amps)
1A per Contact
Contact Material
Phosphor Bronze
Connector Type
Header, Cuttable
Features
-
Ingress Protection
-
Insulation Color
Black
Series
M22
Pitch - Mating
0.079" (2.00mm)
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
-
Row Spacing - Mating
-
Contact Shape
Square
Contact Finish Thickness - Mating
-
Package
Bulk
Mounting Type
Through Hole, Right Angle
Product Status
Obsolete
Contact Finish - Post
Tin
Mfr
Harwin Inc.
Contact Type
Male Pin
Number of Positions
20
Contact Length - Mating
0.138" (3.50mm)
Insulation Height
0.079" (2.00mm)
Operating Temperature
-55°C ~ 105°C
Voltage Rating
-
Mated Stacking Heights
-
Applications
-
Shrouding
Unshrouded
Fastening Type
Push-Pull
Number of Positions Loaded
All
Termination
Solder
Contact Length - Post
0.118" (3.00mm)
Overall Contact Length
-
Number of Rows
1
Insulation Material
Polyamide (PA6T), Nylon 6T
