M22-5331605
M22-5331605
Favorite Products
Share:

M22-5331605

M22-5331605
Harwin Inc.
CONN HEADER SMD R/A 16POS 2MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Mated Stacking Heights
-
Fastening Type
Push-Pull
Insulation Height
0.079" (2.00mm)
Connector Type
Header, Cuttable
Number of Rows
1
Contact Length - Mating
0.165" (4.20mm)
Contact Material
Brass
Applications
-
Series
M22
Package
Bulk
Mfr
Harwin Inc.
Style
Board to Board or Cable
Contact Shape
Square
Contact Finish - Mating
Gold
Contact Finish Thickness - Mating
Flash
Voltage Rating
-
Pitch - Mating
0.079" (2.00mm)
Number of Positions
16
Contact Finish - Post
-
Ingress Protection
-
Contact Finish Thickness - Post
-
Row Spacing - Mating
-
Number of Positions Loaded
All
Insulation Color
Black
Current Rating (Amps)
2A per Contact
Shrouding
Unshrouded
Contact Length - Post
-
Overall Contact Length
-
Operating Temperature
-40°C ~ 105°C
Material Flammability Rating
UL94 V-0
Product Status
Obsolete
Contact Type
Male Pin
Mounting Type
Surface Mount, Right Angle
Termination
Solder
Insulation Material
Polyamide (PA6T), Nylon 6T
Features
-
