M80-5114222
M80-5114222
Favorite Products
Share:

M80-5114222

M80-5114222
Harwin Inc.
CONN HEADER VERT 42POS 2MM
Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Contact Length - Mating
-
Operating Temperature
-55°C ~ 125°C
Base Product Number
M80-511
Connector Type
Header
Style
Board to Board or Cable
Contact Length - Post
0.173" (4.40mm)
Insulation Color
Black
Applications
-
Series
Datamate J-Tek
Overall Contact Length
-
Contact Finish - Post
Tin-Lead
Insulation Material
Polyphenylene Sulfide (PPS), Glass Filled
Features
Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Pitch - Mating
0.079" (2.00mm)
Row Spacing - Mating
0.079" (2.00mm)
Shrouding
Shrouded - 4 Wall
Contact Material
Phosphor Bronze
Current Rating (Amps)
2.2A
Voltage Rating
800V
Package
Tube
Product Status
Active
Contact Type
Male Pin
Number of Positions Loaded
All
Insulation Height
0.220" (5.60mm)
Contact Finish - Mating
Gold
Contact Finish Thickness - Post
118.1µin (3.00µm)
Mfr
Harwin Inc.
Number of Positions
42
Termination
Solder
Contact Finish Thickness - Mating
29.5µin (0.75µm)
Material Flammability Rating
UL94 V-0
Mounting Type
Through Hole
Fastening Type
Threaded
Contact Shape
Circular
Ingress Protection
-
Number of Rows
2
Mated Stacking Heights
7.3mm, 7.7mm, 9.75mm, 10.75mm, 13.35mm, 14.75mm
