M80-5421042
M80-5421042
Favorite Products
Share:

M80-5421042

M80-5421042
Harwin Inc.
CONN HEADER SMD R/A 10POS 2MM
Rectangular Connectors - Headers, Male Pins
Available
RoHS Compliant
Datasheet
Datasheet
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
Contact Length - Post
-
Current Rating (Amps)
2.2A
Contact Material
Copper Alloy
Package
Tube
Number of Positions
10
Number of Positions Loaded
All
Mounting Type
Surface Mount, Right Angle
Termination
Solder
Voltage Rating
800V
Mfr
Harwin Inc.
Connector Type
Header
Overall Contact Length
-
Insulation Height
0.218" (5.55mm)
Contact Finish - Post
Tin
Series
Datamate J-Tek
Product Status
Active
Shrouding
Shrouded - 4 Wall
Fastening Type
Threaded
Contact Shape
Circular
Features
Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
Contact Finish Thickness - Post
118.1µin (3.00µm)
Number of Rows
2
Contact Finish - Mating
Gold
Operating Temperature
-55°C ~ 125°C
Contact Type
Male Pin
Pitch - Mating
0.079" (2.00mm)
Row Spacing - Mating
0.079" (2.00mm)
Contact Finish Thickness - Mating
29.5µin (0.75µm)
Material Flammability Rating
UL94 V-0
Ingress Protection
-
Contact Length - Mating
-
Base Product Number
M80-542
Style
Board to Board or Cable
Insulation Color
Black
Insulation Material
Polyphenylene Sulfide (PPS), Glass Filled
Mated Stacking Heights
-
