PF0553-103NLT
PF0553-103NLT
PF0553-103NLT
Favorite Products
Share:

PF0553-103NLT

PF0553-103NLT
Pulse Electronics Power
INDUCT ARRAY 2 COIL 10.5UH SMD
Arrays, Signal Transformers
Available
RoHS Compliant
Datasheet
Available In Stock
Please send RFQ, we will respond immediately
Just Fill in the content with an*
Contact Information
(You can also Log In and fill in automatically)
*
*
*
*
*
Product Attributes
Type PARAMETERS
DC Resistance (DCR) - Series
67mOhm Max
Number of Coils
2
Tolerance
±20%
Current Rating - Parallel
6 A
Current Rating - Series
3 A
Mounting Type
Surface Mount
Package
Tape & Reel (TR)^^Cut Tape (CT)
Inductance - Connected In Series
42 µH
DC Resistance (DCR) - Parallel
17mOhm Max
Inductance - Connected In Parallel
10.5 µH
Ratings
-
Operating Temperature
-40°C ~ 125°C
Product Status
Active
Package / Case
Nonstandard
Series
PF0553NL
Size / Dimension
0.492" L x 0.492" W (12.50mm x 12.50mm)
Height
0.315" (8.00mm)
Mfr
Pulse Electronics Power
Current Saturation - Parallel
11 A
Shielding
Shielded
Current Saturation - Series
5.6 A
